Ariens Sno-Thro 939003-ST520E - Manual (Page 22)

GB - 24
SPECIFICATIONS
Model Number 939003
Description ST520E
Engine - Tecumseh LH195SA
Engine Power – hp (kW) at
Maximum RPM 5.0 (3.7)
Fast Idle Speed-RPM (min
-1
)
3600 ± 150
Displacement - in. (cc) 11.88 (195)
Electric Start 120V
Fuel See Engine Manual
Tank Capacity - qt. (L) 2.0 (1.96)
Snow Clearing Width - in. (cm) 20 (50.8)
Chute
Rotation Angle 200 °
Impeller
Diameter - in. (cm) 12 (30.5)
Speed-RPM-Max (min
-1
)
1200
Auger
Diameter - in. (cm) 11.0 (27.98)
Speed-RPM-Max (min
-1
)
120
Auger Brake Yes
Drive Clutching Wet Sump Gearbox
Speeds 1 Forward
Pneumatic Tires - in. 10
Size and Weight
Height - in. (cm) 43.13 (109.53)
Length - in. (cm) 51.25 (130.18)
Width - in. (cm) 22.38 (56.84)
Weight - lbs (Kg) 125 (56.7)
