NAPDV SERIES
Installation Instructions
8
Figure 2
(NAPDV06XXPC SHOWN)
(B) x 3
(C) x 2 or 3
(D) x 2 or 3
(E) x 2 or 3
(A)
1
rack (example)
Installation to Rack
1.
Use two or three #10-32 x 3/4" Phillips screws (B), #10
washers, #10 lock washers (D) and #10-32 lock nuts (E) to
secure power strip (A) to rack. (See Figure 2)
NOTE:
Quantity of hardware used in Step 1 will depend on the
mounting application and the number of mounting
holes available.
2.
Connect power strip cables as applicable.
