FL Racks Floor Levelers
The FL floor levelers are designed for use with Chief® Raxxess racks. See the specific installation instructions provided with the rack for
additional installation information.
TOOLS REQUIRED / PARTS INCLUDED
WARNING: FAILURE TO READ, THOROUGHLY UNDERSTAND, AND FOLLOW ALL INSTRUCTIONS CAN RESULT IN SERIOUS
PERSONAL INJURY, DAMAGE TO EQUIPMENT, OR VOIDING OF FACTORY WARRANTY! It is the installer’s responsibility to make
sure all components are properly assembled and installed using the instructions provided.
A (4)
[Floor leveler]
7/16"
INSTALLATION INSTRUCTIONS
1. Thread floor levelers (A) into each corner at the bottom of the
rack. (See Figure 1)
Figure 1
2. Place the rack upright onto the levelers and adjust the levelers
with a wrench, as necessary. (See Figure 2)
Figure 2
IMPORTANT ! : If also installing optional casters, leave
levelers installed and adjust them so they are as close to the
floor as possible, yet still allow movement of the rack on the
casters.
®Chief is a registered trademark of Milestone AV
Technologies. All rights reserved.
1 (A) x 4
(NE1F2823 rack shown)
2 (A) x 4
(NE1F2823 rack shown)
