CHIEF ERD8-12-16-20 - Manual (Page 4)

ERD Series Installation Instructions
4
TOOLS REQUIRED FOR INSTALLATION
PARTS
DIMENSIONS
1/16"
#2
A (1)
[ERD door]
B (4)
[nail glide]
C (1)
[lock bracket]
D (10)
#10 x 5/8"
E1 (1)
E2 (1)
E3 (1)
E4 (1)
E (spacer bag - attached to door)
20.50
520.7
"A"
"A"/2
ERD-16 SHOWN
1.38
34.9
MODEL NUMBER DESCRIPTION DIMENSION "A"
ERD-8 ECONOMY RACK PLEXI DOOR-8 SPACES 15.75 [400.0mm]
ECONOMY RACK PLEXI DOOR-12 SPACES 22.75 [577.9mm]
