ESS-42
Installation Instructions
6
11. Fill the four holes on either end of the center column (A) half
full of wood glue. (See Figure 4)
12. Line up dowels (D) installed on top plate (B) with holes on
center column (A) and insert dowels into holes. (See Figure
4)
13. Use a hammer to gently tap dowels into holes. Place
another piece of wood on top of top plate to prevent hammer
marks. (See Figure 4)
14. Use the damp rag or cloth to wipe off any excess glue.
Figure 4
IMPORTANT ! : Wait at least one hour for the glue to
settle prior to applying any pressure to the unit.
15. Repeat steps for the other speaker stand.
WARNING:
Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all components located on top of each ERSS stand does not
exceed 25 lbs (11.34 kg). Use with products heavier than the
maximum weight indicated may result in instability or collapse
of the rack causing possible injury.
16. Install speakers to stands.
(B)
(A)
12
11
x 4
13
W
ood glue
