Dimensions legend – CHIEF PAC730ABC User Manual
Page 3
Installation Instructions
PAC730A/B/C
3
DIMENSIONS
LEGEND
MEASUREMENTS: [MILLIMETERS]
INCHES
Tighten Fastener
Apretar elemento de fijación
Befestigungsteil festziehen
Apertar fixador
Serrare il fissaggio
Bevestiging vastdraaien
Serrez les fixations
By Hand
A mano
Von Hand
Com a mão
A mano
Met de hand
À la main
Loosen Fastener
Aflojar elemento de fijación
Befestigungsteil lösen
Desapertar fixador
Allentare il fissaggio
Bevestiging losdraaien
Desserrez les fixations
Hex-Head Wrench
Llave de cabeza hexagonal
Sechskantschlüssel
Chave de cabeça sextavada
Chiave esagonale
Zeskantsleutel
Clй а tête hexagonale
