PAC115-116-117 Installation Instructions
2
DISCLAIMER
Milestone AV Technologies and its affiliated corporations and
subsidiaries (collectively "Milestone"), intend to make this
manual accurate and complete. However, Milestone makes no
claim that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Milestone
makes no representation of warranty, expressed or implied,
regarding the information contained herein. Milestone assumes
no responsibility for accuracy, completeness or sufficiency of
the information contained in this document.
Chief® is a registered trademark of Milestone AV Technologies.
All rights reserved.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: A WARNING alerts you to the possibility of
serious injury or death if you do not follow the instructions.
CAUTION: A CAUTION alerts you to the possibility of
damage or destruction of equipment if you do not follow the
corresponding instructions.
WARNING: Failure to read, thoroughly understand, and
follow all instructions can result in serious personal injury,
damage to equipment, or voiding of factory warranty! It is the
installer’s responsibility to make sure all components are
properly assembled and installed using the instructions
provided.
WARNING: Failure to provide adequate structural strength
for this component can result in serious personal injury or
damage to equipment! It is the installer’s responsibility to
make sure the structure to which this component is attached
can support five times the combined weight of all equipment.
Reinforce the structure as required before installing the
component. The wall to which the mount is being attached
may have a maximum drywall thickness of 5/8" (1.6cm) over
steel studs.
WARNING: Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all components does not exceed the maximum weight
capacity of the mount being installed. (See mount installation
instructions for weight capacity information.) Consult Table 1
for Chief mount models which may use the PAC115/116/117
for installation to two steel studs.
WARNING: Use this mounting system only for its intended
use as described in these instructions. Do not use
attachments not recommended by the manufacturer.
WARNING: Never operate this mounting system if it is
damaged. Return the mounting system to a service center for
examination and repair.
WARNING: Do not use this product outdoors.
IMPORTANT ! : The PAC115-116-117 kits may be used to
fasten mounts to a 2" x 4"-25ga minimum steel stud wall.
WARNING: USING THIS PRODUCT INCORRECTLY
MAY RESULT IN SERIOUS PERSONAL INJURY OR
DAMAGE TO EQUIPMENT! Do NOT use the PAC115-116-
117 to fasten a mount into only drywall!
--SAVE THESE INSTRUCTIONS--
Table 1: MOUNT MODELS
MOUNT SERIES
(securing mounts to two steel studs)
iCMPFM2 MSA RLF1
iCMPFM3 MSM RLF2
iCMPTM2 MSMV RMF1
iCMPTM3 MSR RMF2
iCXPFM2 MTA RMT1
iCXPFM3 MTM RMT2
iCXPTM2 MTR RST2
iCXPTM3 MWC RXF2
LSA PLP TS318T
LSM PRO TS325T
LSMV PSM TS525T
LTA PST XSM
LTM PWC XTM
