PAC230/MAC230

Installation Instructions

4

TOOLS REQUIRED FOR INSTALLATION

PARTS

1/8" (included)

PAC230

A (1)

[PAC230 back cover]

B (2)

[PAC230 attach bracket]

C (16)

#10-24 x 1/2"

D (8)

#10

E (1)

1/8"

MAC230

A (1)

[MAC230 back cover]

B (2)

[MAC230 attach bracket]

C (14)

#10-24 x 1/2"

D (6)

#10

E (1)

1/8"
