25
2. Technical Gas Data
a. Gas Specifications
b. Gas Connections
Inlet connection ----------------1/2-inch inch N.P.T.
Inlet supply size ----------------1/2-inch inch N.P.T. (minimum)
Heat input (per dryer) ---------150,000 Btu/Hr (37,800 kcal/hr)
1) Natural Gas
Regulation is controlled by the dryer's gas valve's internal regulator. Incoming supply pressure must
be consistent between a minimum of 6.0 inches (14.92 mb) and a maximum of 12.0 inches (29.9
mb) water column (W.C.) pressure.
2) Liquid Propane (L.P.) Gas
Dryers made for use with L.P. gas have the gas valve's internal pressure regulator blocked open so
that the gas pressure must be regulated upstream of the dryer. The pressure measured at each gas
valve pressure tap must be a consistent 10.5 inches (26.1 mb) water column. There is no regulator
or regulation provided in an L.P. dryer. The pressure must be regulated at the source (L.P. tank) or
an external regulator must be added to each dryer.
* Drill Material Size (D.M.S.) equivalents are as follows:
Natural Gas ........................ #29 = 0.1360” (3.4544 mm).
Liquid Propane Gas ........... #46 = 0.0810” (2.0574 mm).
T
YPE OF
G
AS
N
ATURAL
L
IQUID
P
ROPANE
Manifold Pressure* 3.5 inches W.C. 8.7 mb 10.5 inches W.C. 26.1 mb
Inline Pressure 6.0 - 12.0 inches W.C. 14.92 - 29.9 mb 10.5 inches W.C. 26.1 mb
Shaded areas are stated in metric equivalents
* Measured at outlet side of gas valve pressure tap when gas valve is on.
T
YP E OF
G
AS
L.P.
Conversion
Kit
Part Number
ADC
MODEL
NUMBER
BTU
Per Hour
Rating
kcal/hr
Rating
Natural Liquid Propane
Qty. D.M.S.*
Part
Number
Qty. D.M.S.*
Part
Number
EURO-24 150,000 37,800 3 #29 140820 3 #46 140806 882317
Shaded area is stated in metric equivalent
