Page 10
6
SECTION II
SPECIFICATIONS
A. SPECIFICATIONS
*
Euro-24 reversing dryer available with 3-phase (3ø) motors standard (1/2 HP [0.37 kw] motors).
**
Size of piping to dryer varies with installation conditions. Contact factory for assistance.
***
Contact factory for information not listed, 3-phase (3ø) figures shown are for 3-wire service.
**** Specify air-operated or electromechanical steam damper system. Air-operated steam damper system
must be provided with clean, dry and regulated 80 PSI +/-10 PSI or (5.51 bars +/- 0.69 bars) air supply.
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
Gas
Electric
Steam****
MAXIMUM CAPACITY (DRY WEIGHT)
50 lbs.
22.7 kg
BASKET (TUMBLER) DIAMETER
32-3/4"
83.2 cm
BASKET (TUMBLER) DEPTH
37-1/2"
95.3 cm
BASKET
(TUMBLER) MOTOR
3/4 HP*
0.560 kw
DOOR OPENING
(DIAMETER)
21-1/2"
54.61 cm
BASKET (TUMBLER) VOLUME
18.3 cu. ft.
0.518 cu.m.
DRYERS PER 20'/40' CONTAINER
10/20
DRYERS PER 45'/48' TRUCK
24/26
VOLTAGE AVAILABLE
120-460v 1ш - 3ш 3, 4w 50/60 Hz
APPROX. WEIGHT (UNCRATED)
651 lbs.
295.3 kg
APPROX. WEIGHT (CRATED)
700 lbs.
317.7 kg
HEAT INPUT
150,000 btuh
37,800 kcal/hr
AIRFLOW
750 cfm
21 cmm
INLET PIPE CONNECTION
1/2" F.P.T.**
OVEN SIZE
KW
BTUH
(60
H
Z
)
KCAL/HR
(50 Hz)
20
68,280
17,200
24
81,960
20,650
25
N/A
21,510
30
102,450
25,810
APPLIED VOLTAGE/PHASE/APPROX. AMP DRAW***
KW
208/1ш
240/1ш
208/3ш
240/3ш
380/3ш
416/3ш
460/3ш
60 Hz 50 Hz 60 Hz 50 Hz
60 Hz
50 Hz
50/60 Hz
60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz
20
103
- -
90
87
--
--
- -
--
33
--
--
--
- -
24
--
- -
- -
--
70
--
61
--
--
--
36
31
- -
25
- -
- -
- -
--
--
--
- -
--
40
--
--
--
- -
30
--
- -
- -
--
86
--
75
--
--
--
44
38
- -
VOLTAGE AVAILABLE
120-460v 1ш - 3ш 3, 4w 50/60 Hz
APPROX. WEIGHT
(UNCRATED)
683 lbs.
309.9 kg
APPROX. WEIGHT (CRATED)
733 lbs.
332.3 kg
AIRFLOW
750 cfm
21 cmm
COMPRESSED AIR VOLUME
0.75 cfh
0.02 cmh
AIR CONNECTION
1/8" F.P.T.
STEAM CONSUMPTION
BOILER HP NORMAL LOAD
142 lbs/hr
64.26 kg/hr
4.1
OPERATING PRESSURE
SUPPLY CONNECTION**
RETURN CONNECTION
125 PSI max
8.6 bar
1"
1"
Shaded areas are stated in metric equivalents
