Information necessary for ordering – CEMB USA TR-V User Manual
Page 3
G : 3 wire power supply
F : 1000 Hz low pass filter
E : 10 Hz high pass filter
D : measuring range 0÷10 mm/s
C : RMS detection
B : velocity detection
A : accelerometer
Example of order:
A / B / C / D / E / F / G
TR -
A / B / C / D / E / F / G
TR -
A : type of transducer
V
velocimeter
A
accelerometer
B : dimension measured
0
displacement
(TR-V only)
1
velocity
2
acceleration
(TR-A only)
C : means of detection
0
RMS
1
peak
2
peak-to-peak
D : measuring range
0
0 ÷ 100 µm
6
0 ÷ 1 g
1
0 ÷ 200 µm
7
0 ÷ 5 g
2
0 ÷ 500 µm
8
0 ÷ 10 g
3
0 ÷ 10 mm/s
9
0 ÷ 20 g
4
0 ÷ 20 mm/s
S
special to be defined
5
0 ÷ 50 mm/s
F : low pass filter
0
no filter
1
100 Hz
2
1000 Hz
3
2500 Hz
4
5000 Hz
5
10000 Hz
S
special to be defined
N.B. : the frequency of the
low pass filter must be at least
double than that of the high
pass filter.
G : type of power supply
2
2 wires (current loop)
3
3 wires
E : high pass filter
0
no filter
4
50 Hz
1
5 Hz
5
100 Hz
2
10 Hz
6
1000 Hz
3
20 Hz
S
special to be defined
B A L A N C I N G
M A C H I N E S
Information necessary for ordering
A 1 0 3 2 2 3
