10
Hunter Fan Company 41081-01 • 09/05
6-1. Partially install two screws into the two holes in the bottom of the fan.
6-2. To connect the wires, hold the bare metal leads together and place a wire
nut over them, then twist clockwise until tight.
• Connect the black wire from the fan to the black wire from the light
fixture.
• Connect the white wire from the fan to the white wire from the light
fixture.
Push the wires and wire nuts into the hole in the bottom of the fan.
6-3. Align the keyholes in the globe fitter with the two partially installed
screws. Rotate the fitter counterclockwise to engage the screws in the
narrow ends of the keyholes. Securely tighten the screws.
6-4. Install one A-19 100 Watt bulb into the light socket.
6-5. Partially install the three thumbscrews into the globe fitter.
6-6. Insert the glass globe into the fitter and securely tighten the three
thumbscrews.
6 • Installing the Light Fixture
Steps 6-1 – 6-3 Steps 6-4 – 6-6
umbscrew
Globe
Globe Fitter
Partially
Installed
Screws
