Feed the wire plug through the
center hole of the upper switch
housing, then wrap keyhole slots
around the screws and twist
counterclockwise.
Screw two switch housing
assembly screws from
the hardware bag halfway
into the motor housing. It does
not matter which two screw
holes you choose.
Insert the third screw, found in
the hardware bag, into
place and then tighten all three
screws.
Make sure the upper switch housing is securely
attached to the mounting plate. Failure to properly
secure all 3 assembly screws could result in the switch
housing fixture falling.
Switch Housing & Light Kit
Connect the 9-pin connector
plugs from the motor housing and
switch housing. Make sure to line
up the colored markings on the
connectors.
Switch
Housing
Screw
13
