J&M TB-3500-6000A User Manual
Page 17
Pg. 17
PARTS LIST
Light Kit Assembly
(For Transports Equipped WITHOUT Rear Brakes)
* NOTE: For Models TB-3500A and TB-6000A equipped with optional rear brakes, please see the
following page for Wiring Harness changes and optional Brake-Away Kit and Switch.
#
Part #
Description
#
Part #
Description
1L RLT-L
Light Assembly (L/H)
17 12114-G5-FB
1/2” x 1 1/4” Grade 5 Flange Bolt
1R RLT-R
Light Assembly (R/H)
18 127-HB
1/2” x 7” Hex Bolt
2*
LWH-HHC
Light Wiring Harness (rear only)
19 14LN
1/4” Lock Nut
3*
LE-1B
Light Enhancer (speaker)
20
12-FN
1/2” Flange Nut
4*
MWH-HHC
Main Wiring Harness with Flat
Four Connector End
21
12-N
1/2” Regular Nut
22
38STS
Self Tapping Screw
5
LMB-1
Light Mounting Bracket
23
14STS
1/4” Self Tapping Screw
6
TA-1
Telescoping Arm
24
12-WR
1/2” Regular Washer
7
HDN-12
Handle Nut
25
UBWC-2
Upper Bar Wire Cover
8
EB-1
Extension Bracket
26
WHB-1
Wire Harness Storage Bracket
9
AIS-2
Angle Iron Support
27
RCW-1
Rubber Cap for Storage Bracket
10 SMV-1
SMV
Emblem
28 1434G5B
1/4” x 3/4” Grade 5 Bolt
11 GR-134
Rubber Grommet (large)
29
OMST-1
Manual Storage Container
12 WC-1
Wire
Clip
13 RD-A1
Amber Reflective Decal
14 RD-R1
Red
Reflective
Decal
15 RD-O1
Orange Reflective Decal
16 141-CB
1/4” x 1” Bolt
