NEULOG GALVANIC SKIN RESPONSE SENSOR GUIDE
Procedure:
1.
Connect the GSR sensor directly to the left side of a charged BAT-200
module.
2.
When ready to collect data press the “Start/Stop” button on the GSR sensor,
a red light will turn on for the duration of the experiment.
3.
To change the experiment settings first connect to your chosen device (PC,
Mac, tablet, smart device) and select the “Module setup” button. (For more
information on how to change the experiment settings view quick start
procedure section for your chosen device in this document.)
4.
After the experi
ment has concluded (when the “Start/Stop” button is pressed
again or the data collection period ends) connect the sensor to your chosen
device. (full instructions in each device’s quick start procedure section)
5.
Open NeuLog software.
6.
Click the “Off-line experiment” button.
7.
Click the “Load data from sensors” button.
8.
Select which experimental data to upload. (5 experimental runs can be
stored at one time on the NUL-217 GSR sensor)
Restoring sensor’s factory default settings:
Procedure:
1.
Connect the USB-200 to a PC, Mac, tablet, or smart device.
2.
Connect the GSR sensor to a USB-200 module (they directly plug together).
Please note there is no calibration required for this sensor.
3.
Open the NeuLog software.
4.
Click the “Tools” icon.
5.
Click “Restore sensor’s factory defaults” icon.
6.
If prompted to clear the graph, click either the “Off-line either” or “On-line
experiment” (whichever you are using).
7.
Click “Clear experiment results”.
8.
Resume from step 4.
Included with sensor:
NeuLog NUL-217 GSR sensor guide (this document).
GSR probes (power and ground) attached by durable rubber-coated wires.
Two white Velcro finger connectors.
Sensor specifications
µS
Arbitrary analog
units
Range and
operation modes
0 to 10
0 to 65279
ADC resolution
16 bit
Resolution
10 nS
Max sample rate
(S/sec)
100
Sensor features:
Fully digital data.
Rugged plastic ergonomic case.
Push button switch for Start/Stop experiments in off line mode.
LED indicator of experiment status (blinks while collecting data).
Pre-calibrated sensing equipment.
GSR probes (power and ground) connected to the sensor body by durable
rubber-coated wires.
Note: NeuLog products are intended for educational use.
Videos and experiment examples:
Videos, literature and other probes can be found a
