NEULOG ROTARY MOTION SENSOR GUIDE
information on how to change the experiment settings view quick start
procedure section for your chosen device in this document.)
4. After the experiment has concluded (when the “Start/Stop” button is pressed
again or the data collection period ends) connect the sensor to your chosen
device. (full instructions in e
ach device’s quick start procedure section)
5. Open NeuLog software.
6. Click the “Off-line experiment” button.
7. Click the “Load data from sensors” button.
8. Select which experimental data to upload. (5 experimental runs can be
stored at one time on the NUL-226 rotary motion sensor)
Restoring sensor’s factory default settings:
Procedure:
1. Connect the USB-200 to a PC, Mac, tablet, or smart device.
2. Connect the rotary motion sensor to a USB-200 module (they directly plug
together). Please note there is no calibration required for this sensor.
3. Open the NeuLog software.
4. Click the “Tools” icon.
5. Click “Restore sensor’s factory defaults” icon.
6. If prompted to clear the graph, click either the “Off-line experiment” or “On-
line experiment” (whichever you are using).
7. Click “Clear experiment results”.
8. Resume from step 4.
Included with sensor:
 NeuLog NUL-226 Rotary Motion Sensor Guide (this document).
 Rotary motion revolving head piece attached directly to the sensor body by a
durable rubber-coated wire.
Sensor specifications
Range and
operation modes
ADC
resolution
Resolution
Max
sample
rate
(S/sec)
° 0 to 360
16 bit
0.08
100
Rad/s ±345 0.6
Rad/s 2 ±32,222 11
Rev/s ±55 0.02
Sensor features:
 Fully digital data.
 Rugged plastic ergonomic case.
 Rotary motion rotating head piece attached directly to the sensor body by a
durable rubber-coated wire.
 Push button switch for Start/Stop experiments in off line mode.
 LED indicator of experiment status (blinks while collecting data).
 Pre-calibrated sensing equipment.
 Note: NeuLog products are intended for educational use.
Videos and experiment examples:
 Videos, literature and other probes can be found at www.NeuLog.com
 http://www.NeuLog.com/Products/Rotary MotionloggerSensor.aspx
Technical background:
The philosophy behind NeuLog’s plug and play technology is based on each sensor’s
ability to store its own data due to an internal flash memory chip and micro-controller
in each plastic NeuLog body. This technology allows the sensor to collect and then
store the digital data in the correct scientific units (
o C, o F, Lux, %, ppm, for example).
The sensor is pre-calibrated at the factory. The built-in software in the logger can be
upgraded for free at any time using the provided firmware update.
Inside of the rotary motion sensor a magnet is situated within a metal coil. The
magnet is connected directly to the rotary motion rotating headpiece which causes the
