NEULOG SALINITY SENSOR GUIDE

Procedure:

1.

Connect the salinity sensor directly to the left side of a charged BAT-200
module.

2.

When ready to collect data press the “Start/Stop” button on the salinity
sensor, a red light will turn on for the duration of the experiment.

3.

To change the experiment settings first connect to your chosen device (PC,
Mac, tablet, smart device) and select the “Module setup” button. (For more
information on how to change the experiment settings view quick start
procedure section for your chosen device in this document.)

4.

After the experiment has concluded (when the “Start/Stop” button is pressed
again or the data collection period ends) connect the sensor to your chosen
device. (full instructions in each devi

ce’s quick start procedure section)

5.

Open NeuLog software.

6.

Click the “Off-line experiment” button.

7.

Click the “Load data from sensors” button.

8.

Select which experimental data to upload. (5 experimental runs can be
stored at one time on the NUL-228 salinity sensor)


Restoring sensor’s factory default settings:


Procedure:

1.

Connect the USB-200 to a PC, Mac, tablet, or smart device.

2.

Connect the salinity sensor to a USB-200 module (they directly plug
together). Please note there is no calibration required for this sensor.

3.

Open the NeuLog software.

4.

Click the “Tools” icon.

5.

Click “Restore sensor’s factory defaults” icon.

6.

If prompted to clear the graph, click either the “Off-line experiment” or “On-
line experiment” (whichever you are using).

7.

Click “Clear experiment results”.

8.

Resume from step 4.

Included with sensor:

NeuLog NUL-228 salinity sensor guide (this document).

Salinity probe which is directly attached to the sensor’s plastic body.

Sensor specifications:

Range and

operation

modes

ADC resolution

Resolution

Max sample rate

(S/sec)

0 to 6.4%

16 bit

0.0064%

100

0 to 64,000

mg/L

64 mg/L

0 to 64,000

ppm

64 ppm


Sensor features:

Fully digital data.

Rugged plastic ergonomic case.

Push button switch for Start/Stop experiments in off line mode.

LED indicator of experiment status (blinks while collecting data).

Pre-calibrated sensing equipment.

Salinity sensing electrodes located on the probe which is attached directly to
the sensor’s plastic body.

Note: NeuLog products are intended for educational use.

Videos and experiment examples:

Videos, literature and other probes can be found at

www.NeuLog.com

http://www.NeuLog.com/Products/SalinityloggerSensor.aspx

Properties of sea water and fresh water -

http://www.neulog.com/Portals/3/Users/Experiment E-1 Properties of Sea
Water and Fresh water Ver 3.0.2.pdf

Technical background:


The philosophy behind NeuLog’s plug and play technology is based on each sensor’s
ability to store its own data due to an internal flash memory chip and micro-controller
in each plastic NeuLog body. This technology allows the sensor to collect and then
store the digital data in the correct scientific units (

o

C,

o

F, Lux, %, ppm, for example).

The sensor is pre-calibrated at the factory. The built-in software in the logger can be
upgraded for free at any time using the provided firmware update.
