NEULOG WIDE RANGE TEMPERATURE SENSOR GUIDE
Your wide range temperature sensor needs to be connected to a WIFI-201 module.
The WIFI-201 module will create a closed NeuLog wifi network which will stream the
NeuLog data to a device of your choosing. Once your device is wirelessly connected
to the NeuLog network you can run experiments and collect data through a browser of
your choosing.
Procedure:
1.
Connect the wide range temperature sensor directly to the left side of a
WIFI-201 module (no wires required).
2.
Connect a BAT-200 module to the right side of the WIFI-201 module.
3.
Although not required, we recommend plugging the BAT-200 to an outlet
using a USB to micro USB charger (such as a typical cell phone charger).
The WIFI-201 module will run for 15-75 minutes (depending on the sensor)
without being plugged in.
4.
For further WIFI-201 instructions or the WIFI-201 quick start guide please
visit
5.
The WIFI-201 indicator lights will flash; take no action until the LED to the
far left turns blue.
6.
Take your tablet or smart phone and go to the Wi-Fi settings and select the
NeuLog network which matches the WIFI module ID found on the back of
the WIFI-201 device. (NeuLogXXXX for example)
7.
Give your device 1-2 minutes to connect to the WIFI-201 network.
8.
Once the device is connected go to your browser and type in the website
wifi201.com into the URL bar, then wait for 30-60 seconds.
9.
You will see a “Control mode” icon in the browser, click on this icon.
10. The browser will then load a new screen and begin to auto detect the
sensors, this can take a few minutes.
11. If the browser does not
auto detect, select “Search for sensors”
12. Once the sensor is found you will see an icon on the left side of the screen
for the wide range temperature sensor. The icon will display data in real
time.
13.
To set the wide range temperature sensor’s settings click on “Module setup”
button located on the wide range temperature sensor icon on the left side of
your screen.
14.
To change the experimental settings click the “Experiment setup” button
(experiment duration for example).
15. To run an experiment and collect data
click “Run experiment”.
Operation with NeuLog viewer
Materials needed:
Procedure:
1.
Connect the wide range temperature sensor to the left side of the viewer.
2.
Connect the BAT-200 module to the right side of the viewer.
3.
The VIEW-101 will auto detect the sensor and you will see it appear on the
left side of the screen.
4.
Once the sensor appears it will be monitoring data in real time.
5.
To run an experiment and collect data click the run button (little green
person).
Off-line experiments
(Off-line experiments are for when you do not have a sensor connected directly to a
computer, tablet, smartphone, or NeuLog viewer).
Materials needed:
Materials needed to configure your offline experiment:
A USB to mini USB cable (which comes with the USB-200)
Procedure:
1.
Connect the wide range temperature sensor directly to the left side of a
charged BAT-200 module.
