NEULOG INFRARED TEMPERATURE SENSOR GUIDE
Operation with NeuLog viewer
Materials needed:
Procedure:
1.
Connect the infrared temperature sensor to the left side of the viewer.
2.
Connect the BAT-200 module to the right side of the viewer.
3.
The VIEW-101 will auto detect the sensor and you will see it appear on the
left side of the screen.
4.
Once the sensor appears it will be monitoring data in real time.
5.
To run an experiment and collect data click the run button (little green
person).
Off-line experiments
(Off-line experiments are for when you do not have a sensor connected directly to a
computer, tablet, smartphone, or NeuLog viewer).
Materials needed:
Materials needed to configure your offline experiment:
A USB to mini USB cable (which comes with the USB-200)
Procedure:
1.
Connect the infrared temperature sensor directly to the left side of a
charged BAT-200 module.
2.
When ready to collect data press the “Start/Stop” button on the infrared
temperature sensor, a red light will turn on for the duration of the
experiment.
3.
To change the experiment settings first connect to your chosen device (PC,
Mac, tablet, smart device) and select the “Module setup” button. (For more
information on how to change the experiment settings view quick start
procedure section for your chosen device in this document.)
4.
After the experiment has concluded (when the “Start/Stop” button is pressed
again or the data collection period ends) connect the sensor to your chosen
device. (full instructions in each device’s quick start procedure section)
5.
Open NeuLog software.
6.
Click the “Off-line experiment” button.
7.
Click the “Load data from sensors” button.
8.
Select which experimental data to upload. (5 experimental runs can be
stored at one time on the NUL-235 infrared temperature sensor)
Restoring sensor’s factory default settings:
Procedure:
1.
Connect the USB-200 to a PC, Mac, tablet, or smart device.
2.
Connect the infrared temperature sensor to a USB-200 module (they
directly plug together). Please note there is no calibration required for this
sensor.
3.
Open the NeuLog software.
4.
Click the “Tools” icon.
5.
Click “Restore sensor’s factory defaults” icon.
6.
If prompted to clear the graph, click either the “Off-line experiment” or “On-
line experiment” (whichever you are using).
7.
Click “Clear experiment results”.
8.
Resume from step 4.
Included with sensor:
NeuLog NUL-235 Infrared Temperature Sensor Guide (this document).
