NEULOG SPIROMETER SENSOR GUIDE
The sensor is pre-calibrated at the factory. The built-in software in the logger can be
upgraded for free at any time using the provided firmware update.
Inside of the NeuLog spirometer sensor’s metal tube attachment there is a funnel
which creates a difference in airflow speed as air passes through it. There are also
two pressure sensors for detecting air flow rate before and after entering the funneling
piece. Minor pressure differences before and after the funneling piece are measured
and compared with each other to accurately calculates the flow of air in volume per
second.
Using the NeuLog software, you can easily determine the area under the curve to
calculate total lung capacity.
Maintenance and storage:
Never submerge the NeuLog plastic body in any liquid.
Do not allow liquid into the spirometer sensor’s body.
After use, gently wipe away any foreign material from the spirometer sensor.
Store in a box at room temperature out of direct sunlight.
Warranty:
We promise to deliver our sensor free of defects in materials and workmanship for a
period of 3 years from the date of purchase. Our warranty does not cover damage of
the product caused by improper use, abuse, or incorrect storage. Sensors with a shelf
life such as ion selective proves have a warranty of 1 year. Should you need to act
upon the warranty please contact your distributor. Your sensor will be repaired or
replaced.
Thank you for using NeuLog!
