Cartridge Heaters
Length
Diameter
Lead Length
Watts Catalogue
Dia. Length W V /in 2 Number
Watts Catalogue
Dia. Length W V /in 2 Number
3 /
8
1 100 120 170 CARG01A0069
1 150 120 256 CARG01A0070
1 150 240 256 CARG01A0071
3 /
8
1 1 /
4
50 120 57 CARG01E0072
1 1 /
4
80 120 108 CARG01E0073
1 1 /
4
100 120 114 CARG01E0074
1 1 /
4
125 120 141 CARG01E0075
1 1 /
4
200 120 228 CARG01E0076
1 1 /
4
200 240 228 CARG01E0077
3 /
8
1 3 /
8
150 120 146 CARG01G0078
3 /
8
1 7 /
16
100 120 91 CARG01H0079
1 7 /
16
130 240 118 CARG01H0080
3 /
8
1 1 /
2
30 120 25 CARG01J0081
1 1 /
2
50 120 42 CARG01J0082
1 1 /
2
60 120 51 CARG01J0083
1 1 /
2
75 120 64 CARG01J0084
1 1 /
2
85 120 72 CARG01J0085
1 1 /
2
100 240 86 CARG01J0086
1 1 /
2
150 120 127 CARG01J0087
1 1 /
2
150 240 127 CARG01J0088
1 1 /
2
200 120 170 CARG01J0089
1 1 /
2
200 240 170 CARG01J0090
1 1 /
2
250 120 212 CARG01J0091
1 1 /
2
250 240 212 CARG01J0092
1 1 /
2
250 240 212 CARG01J0093
3 /
8
1 3 /
4
125 120 86 CARG01N0094
1 3 /
4
150 240 102 CARG01N0095
1 3 /
4
175 120 120 CARG01N0096
1 3 /
4
200 240 136 CARG01N0097
1 3 /
4
200 240 136 CARG01N0098
1 3 /
4
250 120 163 CARG01N0099
1 3 /
4
250 240 163 CARG01N0100
1 3 /
4
250 240 163 CARG01N0101
3 /
8
2 50 120 28 CARG02A0102
2 75 120 42 CARG02A0103
2 100 120 57 CARG02A0104
2 100 240 57 CARG02A0105
2 150 120 85 CARG02A0106
2 150 120 85 CARG02A0107
2 150 240 85 CARG02A0108
2 165 240 94 CARG02A0109
2 200 120 114 CARG02A0110
2 200 240 114 CARG02A0111
2 250 120 141 CARG02A0112
2 250 240 141 CARG02A0113
2 250 240 141 CARG02A0114
2 300 120 170 CARG02A0115
2 300 240 170 CARG02A0116
2 400 120 226 CARG02A0117
2 400 240 226 CARG02A0118
3 /
8
2 1 /
4
75 120 37 CARG02E0119
2 1 /
4
125 120 62 CARG02E0120
2 1 /
4
125 240 62 CARG02E0121
2 1 /
4
250 120 121 CARG02E0122
3 /
8
2 1 /
4
250 240 121 CARG02E0123
2 1 /
4
250 240 121 CARG02E0124
3 /
8
2 3 /
8
75 120 34 CARG02G0125
2 3 /
8
165 120 75 CARG02G0126
2 3 /
8
165 120 75 CARG02G0127
2 3 /
8
165 240 75 CARG02G0128
2 3 /
8
200 120 91 CARG02G0129
2 3 /
8
200 240 91 CARG02G0130
2 3 /
8
200 240 91 CARG02G0131
2 3 /
8
250 120 113 CARG02G0132
2 3 /
8
250 240 113 CARG02G0133
2 3 /
8
300 120 136 CARG02G0134
2 3 /
8
300 240 136 CARG02G0135
2 3 /
8
400 120 181 CARG02G0136
3 /
8
2 1 /
2
100 120 42 CARG02J0137
2 1 /
2
100 240 42 CARG02J0138
2 1 /
2
250 240 141 CARG02J0139
2 1 /
2
400 240 174 CARG02J0140
2 1 /
2
500 120 215 CARG02J0141
2 1 /
2
500 240 215 CARG02J0142
3 /
8
2 3 /
4
100 120 38 CARG02N0143
2 3 /
4
200 120 76 CARG02N0144
2 3 /
4
250 120 95 CARG02N0145
2 3 /
4
275 240 104 CARG02N0146
2 3 /
4
300 240 114 CARG02N0147
2 3 /
4
500 240 190 CARG02N0148
