Cartridge Heaters
Length
Diameter
Lead Length
Watts Catalogue
Dia. Length W V /in 2 Number
Watts Catalogue
Dia. Length W V /in 2 Number
18 4700 240 135 CARL18A0597
5 /
8
20 1000 240 27 CARL20A0598
20 2500 240 66 CARL20A0599
20 4700 240 122 CARL20A0600
5 /
8
22 1000 240 25 CARL22A0601
3 /
4
3 500 240 85 CARN03A0602
3 /
4
3 3 /
4
500 240 65 CARN03N0603
3 3 /
4
1000 240 131 CARN03N0604
3 /
4
4 300 240 38 CARN04A0605
4 525 240 66 CARN04A0606
4 525 240 66 CARN04A0607
4 1000 240 122 CARN04A0608
3 /
4
4 1 /
2
350 120 42 CARN04J0609
3 /
4
4 3 /
4
750 240 75 CARN04N0610
3 /
4
5 500 240 49 CARN05A0611
5 500 240 49 CARN05A0612
5 700 240 68 CARN05A0613
5 1000 240 95 CARN05A0614
3 /
4
5 3 /
4
1000 240 81 CARN05N0615
5 3 /
4
1100 240 89 CARN05N0616
3 /
4
6 350 120 28 CARN06A0617
6 350 240 28 CARN06A0618
6 500 240 39 CARN06A0619
6 750 240 59 CARN06A0620
6 1100 240 87 CARN06A0621
6 1500 240 115 CARN06A0622
3 /
4
7 500 240 33 CARN07A0623
7 1000 240 65 CARN07A0624
3 /
4
7 1 /
2
450 120 32 CARN07J0625
3 /
4
7 3 /
4
1350 240 79 CARN07N0626
3 /
4
8 350 240 20 CARN08A0627
8 500 240 28 CARN08A0628
8 600 240 36 CARN08A0629
8 700 240 40 CARN08A0630
8 1000 240 68 CARN08A0631
8 1350 240 78 CARN08A0632
8 2000 240 115 CARN08A0633
3 /
4
9 2000 240 101 CARN09A0634
3 /
4
9 3 /
4
2000 240 92 CARN09N0635
3 /
4
10 600 240 27 CARN10A0636
10 800 240 36 CARN10A0637
10 800 240 36 CARN10A0638
10 1000 240 46 CARN10A0639
10 1200 240 54 CARN10A0640
10 2000 240 49 CARN10A0641
3 /
4
11 3 /
4
1000 240 37 CARN11N0642
11 3 /
4
1500 240 56 CARN11N0643
11 3 /
4
2000 240 75 CARN11N0644
3 /
4
12 600 240 46 CARN12A0645
12 800 240 54 CARN12A0646
12 950 240 49 CARN12A0647
12 1500 240 56 CARN12A0648
12 2000 240 75 CARN12A0649
3 /
4
13 1000 240 34 CARN13A0650
3 /
4
14 1100 240 35 CARN14A0651
14 1400 240 45 CARN14A0652
14 2500 240 78 CARN14A0653
3 /
4
14 3 /
4
1500 240 44 CARN14N0654
3 /
4
16 1000 240 28 CARN16A0655
16 1250 240 35 CARN16A0656
16 1500 240 44 CARN10A0657
16 1800 240 49 CARN16A0658
3 /
4
18 1450 240 35 CARN18A0659
18 2000 240 49 CARN18A0660
3 /
4
20 2200 240 48 CARN20A0661
3 /
4
24 1950 240 35 CARN24A0662
24 2750 240 50 CARN24A0663
