REV2
ITEM DESCRIPTION REV PART NO. QTY ITEM DESCRIPTION PART NO. QTY
1 BAR HOLDER 0 UP5180 2 36 FLAT WASHER SAE Z/P 1/2" BNH2031 14
2 BOTTOM CROSS BRACE 0 UP5181 1 37 FLAT WASHER SAE Z/P 3/8" BNH2030 80
3 BOTTOM SIDE FRAME LT 0 UP7043 1 39 HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 1 1/4 BNH2167 8
4 BOTTOM SIDE FRAME RT 0 UP7044 1 40 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 1 3/4 BNH2040 4
5 PRESS BAR HOUSING LT 0 UP7045 1 41 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 2 3/4 BNH2045 4
6 PRESS BAR HOUSING RT 0 UP7046 1 42 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 3 BNH2046 8
7 NICKEL FRONT UPRIGHT 0 UP5270 2 43 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 3/4 BNH2036 8
8 LINEAR SHAFT 1 X 69 11/16 0 UP5187 2 44 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 5 BNH2051 4
9 OLYMPIC ADAPTER 1 X 8 0 UP5188 10 45 HEX KEY ALLOY 3/32" BNH0372 1
10 REAR SIDE SUPPORT LT 0 UP7047 1 46 HEX KEY ALLOY 7/32" BNH0575 1
11 REAR SIDE SUPPORT RT 0 UP7048 1 47 INTERNAL RETAINING RING 1 9/16" BNH0095 4
12 SAFETY HOOK LT 0 UP7049 1 48 LINEAR BEARING BNH0770 4
13 SAFETY HOOK RT 0 UP7050 1 49 NYLON BUSHING 1 X 1 1/2 X 7/8 X 1 3/4 X 1/8 BNH0531 4
14 SAFETY SPOTTER BRACKET LT 0 UP7051 1 50 NYLON INSERT JAM LOCK NUT Z/P 3/8-16 BNH2026 20
15 SAFETY SPOTTER BRACKET RT 0 UP7052 1 51 PLASTIC INSERT CAP 1 7/8" RD. BNH0003 12
16 SAFETY SPOTTER POST 0 UP7053 2 52 PLASTIC INSERT CAP ELLIPTICAL 2 X 4 BNH1794 4
17 SAFETY SPOTTER PIN 0 UP5196 32 53 PLASTIC INSERT ELLIPTICAL GUIDE (2 3/8 X 4 3/4) BNH2062 8
18 SHAFT RETAINER PLATE 0 UP5197 2 54 ROLL PIN Z/P 1/4 X 9/16 BNH2090 4
19 SIDE BAR SAFETY SPOTTER 0 UP5198 2 55 RUBBER DONUT 1 X 2 1/2 BNH0062 4
20 TOP CROSS BRACE 0 UP5199 1 56 RUBBER FOOT FOR 6 X 4 1/4 PLATE BNH1647 4
21 WEIGHT LIFT BAR 0 UP7054 1 57 RUBBER GRIP 1.1875 ID X .125 X 17 BNH0953 2
22 TOP STABILIZER 0 UP5256 1 58 RUBBER WASHER 1 7/8 ID X 4 1/4 OD X 9/16 TK BNH0933 12
23 ABS SLEEVE 1 1/2 X 8 1/8 BNH1527 10 59 SAFETY SPOTTER PLASTIC STRIP BNH2078 2
24 ALUMINUM CAP 1.270" RD BNH0538 2 60 SOCKET SET SCREW Z/P 10-32 X 1/8 BNH2088 4
25 BLACK RUBBER GRIP 1/2 X 4 7/8 BNH1818 2 62 SPLIT LOCK WASHER Z/P 1/2" BNH0572 10
26 BRONZE BUSHING Ø25 X Ø19 X 20 mm BNH1926 2 63 SPLIT LOCK WASHER Z/P 3/8" BNH2032 40
27 BRONZE BUSHING Ø31 X Ø25.4 X Ø19 X 20 mm BNH1925 2 64 TUFFSTUFF LOGO ALUMINUM SMALL BNH1323 1
28 BUTTON HEAD SOCKET CAP SCREW B/O 3/8-16 X 1 BNH0115 32 65 TURN/PULL PIN W/KNOB AND LOCK BNH0989 4
29 DECAL-DANGER ENGAGE SAFETY SPOTTER... BNH1848 2 66 ABS SLEEVE 1 1/2 X 13 BNH2260 2
30 DECAL-IMPORTANT FOR BEST PERFORMANCE... BNH1894 2 67 HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 4 3/4 BNH2168 2
31 DECAL-CAUTION WEIGHT TRAINING SAFETY… BNH0126 1 68 HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 1 1/2 BNH2171 2
32 DECAL-WARNING ATTENTION USERS! MOVING... BNH1895 2 69 HEX KEY ALLOY 5/32" BNH0373 1
33 FLAT HEAD SOCKET CAP SCREW Z/P M7X1.0 BNH2079 6 70 NYLON INSERT JAM LOCK NUT Z/P 1/2-13 BNH2027 2
34 FLAT PHILLIPS MACHINE SCREW 8-32 X 1/4 BNH0408 4 71 NYLON SNAP-IN FINISHING PLUG 3/8" BNH0720 20
35 FLAT PHILLIPS SCREW ZINC # 2 X 1/2 BNH1480 2 72 URETHANE BUMPER 962 BNH0244 2
RSM-600
Parts List
COLOR CHART
BOLD FONT = SUB-ASSEMBLY PARTS
BLACK= HARDWARE
13 RSM-600 Basic Smith-Half Cage
RSM-600 Parts List
