Excellon 235785-01/02

FAN MOTORS

SPECIFICATIONS:

H.P. 1/4

VOLTAGE - 220/230/460 3 phase

HZ-50-60

RPM: 1725

OVERLOAD - Automatic, Internal

FRAME – L48Y

MTG – Rigid, open motor

CAT. NO.

Baldor – Spec #34F507X672G1

ROTATION:

Motor runs clockwise (CW).

FAN BLADE:

16" x 31

SAFETY: Avoid personal injury or equipment damage by disconnecting electrical
power before working on the motor. Make sure the power is off when checking each
phase.

MAINTENANCE:

1. There are no lubrication points, therefore, no lubrication is necessary.
2. Make sure the blade runs in the correct rotation.
3. Clean the outside of the fan motor as necessary.
