400AC 33
PARTS LIST
400AC/WC - 460/3 or 230/3
If this unit has special feature(s) installed, see appendix for part number(s).
Part Number Description 460/3 230/3 Qty.
Refrigeration
R117 Compressor – 230/3 – 4 HP ü 1
R118 Compressor – 440/3 – 4 HP ü 1
R124 Condenser – Air Cooled ь ь 1
R124-W Condenser – Water Cooled ь ь 1
R132 Receiver 5 Ton ь ь 1
R140-5 Expansion Valve – 5 HW ь ь 1
R141-1 Expansion Valve Flange ь ь 1
R146-1 Refrigeration Sight Glass ь ь 1
R152 Refrigeration Drier – 3/8” ь ь 1
R167 Evaporator (All Copper) ь ь 1
R180 Suction Line Heat Exchanger ь ь 1
R182 High Pressure Switch ь ь 1
R183 Low Pressure Switch ь ь 1
Electrical ь ь
E101 Disconnect – 80 Amp ь ь 1
E101-H Disconnect Handle Only ь ь 1
E101-S Disconnect Shaft Only ь ь 1
E103 Contactors – 30 Amps ь ь 2
E104 4 Point Terminal Block ь ь 1
E112 Transformer – 220/3 ü 1
E113 Transformer – 440/3 ü 1
E115 Grounding Screw ь ь 1
E122 Off/On Switch ь ь 2
E124-3 Pilot Light Bulb – 24v ь ь 2
E126 Pilot Light Assembly ь ь 2
E128A Solid State Compact Control Board Half to 4 Ton ь ь 1
E128P-D Discharge Probe Wire ь ь 14 ft
E128P-R Return Probe Wire ь ь 14 ft
E132 Thermostat ь ь 1
E134 Dial Thermometer ь ь 1
E145 Fan Motor – ½ HP ь ь 1
E148 Fan Blade – 18” ь ь 1
E153-20 Fan Guard for 18” Blade ь ь 1
Plumbing
P124-S 2 HP Stainless Steel Pump ь ь 1
P145-2S Seal and “O” Ring Kit for Water Pump ь ь 1
P149-WSGA Water Sight Glass Assembly ь ь 1
P151-WSG Water Sight Glass Only ь ь 1
P160-2 Stainless Steel Tank – 5 Ton ь ь 1
