FAN MOTOR SPECIFICATIONS
Refer to your model number & voltage
Model # H.P.
Voltage
Hz R.P.M. Overload Frame Mounting Rotation
Blade
QTY.
50AC
1/4 Hp 115/208/230-1 Ph. 60
1725
Automatic
G48
Rigid O.D.P.
CW
14" x 16 Pitch
1
100AC
1/4 Hp 115/208/230-1 Ph. 60
1725
Automatic
G48
Rigid O.D.P.
CW
16" x 26 Pitch
1
100AC
1/4 Hp
460-3 Ph.
60
1140
Automatic
L48
Rigid O.D.P.
CW
16" x 26 Pitch
1
150AC
1/4 Hp 208/230/460-3 Ph. 60
1140
Automatic
L48
Rigid O.D.P.
CW
16" x 26 Pitch
1
200AC
1/2 Hp 208/230/460-3 Ph. 60
1140
Automatic
F56
Rigid O.D.P.
CW
18" x 24 Pitch
1
300AC
1/2 Hp 208/230/460-3 Ph. 60
1140
Automatic
F56
Rigid O.D.P.
CW
18" x 24 Pitch
1
400AC
1/2 Hp 208/230/460-3 Ph. 60
1140
Automatic
F56
Rigid O.D.P.
CW
18" x 24 Pitch
1
500AC
1/2 Hp 208/230/460-3 Ph. 60
1140
Automatic
F56
Rigid O.D.P.
CW
18" x 24 Pitch
1
600AC
1/2 Hp 208/230/460-3 Ph. 60
1140
Automatic
F56
Rigid O.D.P.
CW
18" x 24 Pitch
2
750AC
1/2 Hp 208/230/460-3 Ph. 60
1140
Automatic
F56
Rigid O.D.P.
CW
18" x 24 Pitch
2
800AC
1/2 Hp 208/230/460-3 Ph. 60
1140
Automatic
F56
Rigid O.D.P.
CW
18" x 24 Pitch
2
1001AC 1/2 Hp 208/230/460-3 Ph. 60
1140
Automatic
F56
Rigid O.D.P.
CW
18" x 24 Pitch
2
1000AC 1/2 Hp 208/230/460-3 Ph. 60
1140
Automatic
F56
Rigid O.D.P.
CW
18" x 24 Pitch
2
1250AC 1/2 Hp 208/230/460-3 Ph. 60
1140
Automatic
F56
Rigid O.D.P.
CW
18" x 24 Pitch
2
1500AC
1 Hp 208/230/460-3 Ph. 60
1725
Automatic
E56
Rigid O.D.P.
CW
24" x 16 Pitch
2
2000AC
1 Hp 208/230/460-3 Ph. 60
1725
Automatic
E56
Rigid O.D.P.
CW
24" x 16 Pitch
2
2500AC
1 Hp
230/460-3 Ph.
60
1725
Automatic
E56
Rigid O.D.P.
CW
24" x 16 Pitch
3
3000AC
1 Hp
460-3 Ph.
60
1725
Automatic
E56
Rigid O.D.P.
CW
24" x 16 Pitch
3
SAFETY:
Avoid personal injury or equipment damage by disconnecting electrical power before working on the motor(s).
Do not remove the door(s) while the unit is connected to electrical power.
MAINTENANCE:
1. There are no lubrication points; therefore, no lubrication is necessary
2. Make sure the blade runs in the correct direction.
3. Clean the outside of the motor as necessary.
