FAN MOTORS

AIR COOLED

SPECIFICATIONS:

H.P. 1 – 2 each

VOLTAGE - 460/200/230 PHASE 3

HZ-50-60

RPM 1725

OVERLOAD - Automatic, Internal

FRAME - LA56

MTG - Rigid, Open Motor

CAT. NO.

Leeson - 114348

ROTATION:

Motor runs clockwise (CW) or counterclockwise (CCW) as marked.

FAN BLADE:

24" x 23

CW – 2 each. Rotation is looking down on unit.

SAFETY:

Avoid personal injury or equipment damage by disconnecting
electrical power before working on the motor. Make sure the power
is off when checking each phase.

MAINTENANCE:

1.

There are no lubrication points, therefore, no lubrication is necessary.

Make sure the blade runs in the correct rotation.

Clean the outside of the fan motor as necessary.
