MoTeC Using the GPS 3
Software Version
The MoTeC device must be running the following software version (or higher)
SDL3 Version 2.2 or higher
ADL3 Version 5.2 or higher
ACL Version 1.1 or higher
M84 Version 1.10K2 or higher
M400/M600/M800/M880 Version 3.51U2 or higher
M84/M400/M600/M800/M880 ECU Setup
Ensure you are using the GPS-L5 unit. In the relevant MoTeC ECU Manager
software on the Adjust menu click General
Setup>Communications>RS232 Telemetry Setup
o Enter Telemetry Baud Rate 19201
o Enter Telemetry Data Set 0 to turn the dataset Off
The M84 and 'Hundred Series' ECUs only process channels with 16 bit
resolution. While logging, the 32 bit channels Time, Longitude and Latitude
will be split into two 16 bit values. When viewing the data, using i2 data
analysis software, the original 32 bit values will be reassembled.
ECU Data Logging Setup
In the relevant MoTeC ECU Manager software on the Adjust menu click
General Setup>Data Logging Setup>GPS
o Enter GPS Latitude HW 10
o Enter GPS Latitude LW 10
o Enter GPS Longitude HW 10
o Enter GPS Longitude LW 10
o Enter GPS Speed 10.
