Chenbro SK32303 6Gb/s 3-port 3.5 SATA/SAS Backplane for SK32303 - Manual User Manual
Page 7
3-Port 6Gb/s SAS Backplane 80H10532304A0
User’s Manual
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 e-mail: [email protected]
7
www
.chenbr
o.com
SGPIO SIGNAL Connector (CN04)
Front Panel LED Board Connector (CN08)
ATX 8P Connector (CN12, CN22, CN32)
Pin NO.
Description
Pin NO.
Description
1
SGPIO DATA INPUT
2
NC
3
SGPIO DATA OUTPUT
4
GND
5 GND 6
SGPIO
LOAD
7 CONTROL
TYPE 8 SGPIO
CLOCK
9 NC
10
KEY
PIN
Pin NO.
Descriptions
Pin NO.
Descriptions
1
NC
2
Temp Fail LED Out
3
NC
4
Fan Fail LED Out
5
NC
6
Global Fail LED Out
7 NC 8
+5V
9 NC 10
GND
11 NC 12
GND
13 Mute+ 14
Key
Pin
Pin NO.
Descriptions
1 GND
2 RP
3 RN
4 GND
5 TN
6 TP
7 GND
