4-Port SATA II Backplane 80H10211202A0 ver. A0
User’s Manual
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: [email protected]
www
.chenbr
o.com
Hardware Specification
Specification
Host Interface
SATAII
HDD Interface
SATA / SAS
Hot-Swap
Yes, allows user to on line replace Hard Disk Drive
Display
LED indicates Hard Disk Drive status ( Defined by Chenbro )
Power LED – Blue ( When HDD is present )
Access LED –Green ( When HDD is busy )
Error LED –Red ( When HDD is error )
Cooling
3pin Fan connector x2
Connectors
1. SATA II x 4
2. SAS 29pin x 4 ( for HDD )
3. Standard 4pin Power connector x 2 for +5V, +12V from power supply
4. PSU alarm
Dimension
130 ( Length ) x 120. ( Width ) x 1.6 ( Thickness ) mm
Accommodated Chassis
z SR11269
