Hardware specification, Accommodated chassis – Chenbro RM31408 6Gb/s 4-port 3.5 SATA/SAS Backplane(80H10331405A0) - Manual User Manual
Page 5
5
4-Port 6Gb/s SAS/SATA II Backplane 80H10331405A0
User’s Manual
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: [email protected]
w
w
w
.
c
h
e
n
b
r
o
.
c
o
m
Hardware Specification
Specification
Host Interface
SATAII
HDD Interface
SATA / SAS
Hot-Swap
Yes, allows user to on line replace Hard Disk Drive
Display
LED indicates Hard Disk Drive status ( Defined by Chenbro )
Power LED – Blue ( When HDD is present )
Access LED –Green ( When HDD is busy )
Error LED –Red ( When HDD is fail )
Cooling
3pin Fan connector x2
Connectors
1. SATA II x 4
2. SAS 29pin x 4 ( for HDD )
3. Standard 4pin Power connector x 2 for +5V, +12V from power supply
4. PSU alarm mute and fail signal
5. SGPIO
Dimension
114.8 ( Length ) x 107.8 ( Width ) x 2.4 ( Thickness ) mm
Accommodated Chassis
RM31408
