Chenbro RM418 Series 6Gb/s 12-port 3.5 mini-SAS Expander Backplane(80H10323501A0), Rev.A0 - Manual User Manual
Page 10
12-Port 6Gb/s Expander on Backplane 80H10323501A0
User’s Manual
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: [email protected]
10
www
.chenbr
o.com
Pin
NO.
Descriptions
Pin
NO.
Descriptions
S1
GND
P1
NC
S2
RP
P2
NC
S3
RN
P3
NC
S4
GND
P4
GND
S5
TN
P5
POWER ENABLE
S6
TP
P6
GND
S7
GND
P7
5V PRE-CHARGE
S8
NC
P8
5V
S9
NC
P9
5V
S10
NC
P10
GND
S11
NC
P11
ACCESS SIGNAL
S12
NC
P12
GND
S13
NC
P13
12V PRE-CHARGE
S14
NC
P14
12V
P15
12V
