SAS Expander Backplane Assembly Outlook
HDD Side
Host Side
p/n : 80H10341802A0 (2.5” 24-port Mini SAS Backplane Layout)
Components
Description
Function
JP1 ~ JP6
DC in, 4-Pin connector
For backplane power source from power supply
CE1 ~ CE8
bridge board connecter
Connection for SAS Expander daughter board
CN011 ~
CN241
SATAII / SAS HDD connecter
Connect to 22pin SATAII or 29pin SAS 2.5” HDD
CN011
JP1 JP2
JP3
JP4
JP5
JP6
CE1 CE2
CE3 CE4
CE5 CE6
CE7 CE8
CN241
