6
Replacement Parts List for Models J10500
Item Part# for model: J10500 description Qty
1 244-6-1801-306 Top Nut 1
2 248-3-1812-109 Reservoir 1
3 324-4-1900-208 Filler Screw Assembly 1
4 601-4-0080-009 Spring Pin 2
5 248-6-1806-102 Carry Handle 2
6 * 248-6-1201-108 Ram Plunger 1
7 532-8-0050-024 Filter 1
8 N/A Base 1
9 238-6-1701-403 Release Valve 1
10 248-6-1302-104 Support Link, Pump 2
11 518-4-0127-209 Link Pin 1
12 * G35-3-1500-208 High Volume Cartridge 1
13 531-3-0320-002 Crush Washer, H.V. 1
14 248-6-1401-106 Pump Cylinder, H.V. 1
15 248-5-1306-106 Pump Piston, H.V. 1
16 428-6-1602-209 Pump Piston Link, H.V. 1
17 248-6-1301-102 Handle Sleeve, H.V. 1
18 513-5-0016-018 Spring Clip 4
19 518-4-00100-108 Handle Sleeve Pivot Pin 2
20 * 137-4-1500-203 Low Volume Cartridge 1
21 531-3-0190-014 Crush Washer, L.V. 1
22 248-6-1403-302 Pump Cylinder, L.V. 1
23 248-6-1306-203 Pump Piston, L.V. 1
24 566-4-0070-202 Handle Sleeve Link Pin 1
25 248-3-1309-100 Handle Sleeve Link 1
26 248-5-1301-106 Handle Sleeve, L.V. 1
27 248-3-2100-109 Operating Handle 1
28 248-3-9905-106 Repair Kit (a thru bb) 1
(*) Replacement requires special skills, knowledge, and equipment. Only a BVA Authorized Service
Center may perform the repair and/or replacement of these items. Contact BVA Technical
Service for list of Service Centers.
N/A- Not user serviceable
