3
! Be sure all tools and personnel are clear
before lowering load. Only attachments and/or
adapters supplied by the manufacturer shall be used.
Lift only on areas of the vehicle as specified by the
vehicle manufacturer.
! WARNING
• Study, understand, and follow all printed materials
provided with/on this product before use.
• do not exceed rated capacity.
• this is a lifting device only!
• Immediately after lifting, support the load with
a pair of appropriately rated jack stands.
• Use only on hard, level surface.
• Do not use adapters or accessories that are not
provided initially.
• Lift only on areas of the vehicle as specified by the
vehicle manufacturer.
• No alterations shall be made to this product.
• Failure to heed these markings may result in
personal injury and/or property damage.
To avoid crushing and related injuries:
• never work on, under or around a load supported
only by hydraulic jack.
• always use adequately rated jack stands.
• Chock each unlifted tire in both directions.
• do not use this device to lift, level, lower, support nor
move a house, mobile home, travel trailer, camper or
any building structure.
• Be alert and sober when using this product. Do not
operate under the influence of drugs or alcohol.
!
WARNING
X
OPeRatIOn
( refer to Fig. 1)
Raising the Ram Plunger
1. Assemble handle, ensure that spring clips align with slots.
2. Place vehicle in the park, with emergency brake on and wheel securely chocked to prevent inadvertent vehicle
movement.
3. Locate and close release valve by turning handle clockwise until firm resistance is felt to further thread
engagement.
4. Verify lift point, center jack saddle under lift point.
5. Insert the handle into the low pressure, high volume pump handle sleeve. Pump in order to raise saddle to
contact lift point. To lift, insert the handle into the high pressure, low volume pump handle sleeve and to continue
pump until load reaches desired height.
6. Immediately secure lifted load with appropriately rated jack stands.
Use only the handle provided by jack manufacturer. The handle provided with this jack will safely engage
the release valve. If handle is worn, operates abnormally, or will not positively engage the release valve,
STOP, discontinue use of the jack until a factory replacement handle can be acquired.
Do not use an extender on the operating handle.
Lowering
Make certain that all personnel are clear of the load before lowering. Control the rate of descent of the
load at all times. The more you open the release valve, the faster the load descends.
1. Raise load high enough to clear the jack stands, then carefully remove jack stands ( always used in pairs).
2. Slowly turn the handle counter-clockwise, but no more than 1 turn. If the load fails to lower:
a. Use another jack to raise the vehicle high
enough to reinstall jack stands.
b. Remove the affected jack and then the stands.
c. Lower the load by turning the release valve counter-clockwise, but no more than 1 turn.
3. After removing jack from under the load, push ram and handle sleeve down to reduce exposure to rust and
contamination.
!
!
!
