Page 7
Item
Model J11100
Model J11200
Description
Qty.
1
125-6-1103-102
135-6-1103-100
Saddle
1
2
A24-6-4302-107
430-6-4302-406
Retaining Ring
1
3
125-6-1808-100
226-6-1808-106
Retaining Ring
1
4
*
*
O-ring
1
5
125-6-1204-108
135-6-1204-106
Dust Seal
1
6
*
*
O-ring
1
7
N/A
N/A
Ram Plunger
1
8
125-6-1209-108
135-6-1209-106
Ram Bearing
1
9
*
*
Back-up Ring
1
10
*
*
U-cup
1
11
N/A
N/A
Base Assy.
1
12
505-9-0092-207
505-9-0092-207
Oil Filler Plug
1
13
238-6-1701-403
238-6-1701-403
Release Valve
1
14
*
*
Oil Seal
1
15
511-2-0052-001
512-2-0052-008
Spring
1
16
115-6-1603-104
115-6-1603-104
Screw
1
17
*
*
O-ring
1
18
*
*
Back-up Ring
1
19
125-6-1306-106
125-6-1306-106
Pump Piston
1
20
518-4-0080-016
518-4-0080-016
Pin
2
21
125-4-1300-102
125-4-1300-102
Handle Sleeve
1
22
677-5-0070-101
677-5-0070-101
“E” Clip
2
23
125-4-2100-109
135-4-2100-107
Handle
1
24
601-7-0006-005
601-7-0006-005
Steel Ball
2
25
511-2-0048-000
511-2-0048-000
Spring
1
26
*
*
Gasket
1
27
649-1-0080-027
649-1-0080-027
Socket Head Bolt
1
28
509-9-0145-109
509-9-0145-109
Safety Valve Cap
2
29
414-6-1215-307
414-6-1215-307
Safety Valve Screw
1
30
*
*
O-ring
1
31
512-2-0067-010
512-2-0067-010
Spring
1
32
414-6-1216-107
414-6-1216-107
Needle
1
(*)
125-3-9901-102
135-3-9901-100
Repair Kit
-
7
(*) - Indicates items included in, and available only as part of Seal Kit.
N/A - Part is not available as replacement.
Mini Jacks
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
MODELS: J11100 &J11200
Parts List
J11050-M0
rev 08/07
Note: Not all components of the jack are replacement items, but are illustrated as a
convenient reference of location and position in the assembly sequence.
