BVA Hydraulics J11100, J11200 - Manual (Page 5)

Item Model J11050 Model J11055 Description Qty.
1 115-6-1103-104 115-6-1103-104 Saddle 1
2 115-6-1110-101 115-6-1110-101 Retaining Ring 2
3 115-6-1810-109 115-6-1810-109 Upper Bearing 1
4 580-7-0270-101 580-7-0270-101 Dust Seal 1
5 N/A N/A Ram Plunger 1
6 * * Back-up Ring 1
7 * * U-cup 1
8 599-7-0360-002 599-7-0360-002 Special Washer 1
9 N/A N/A Base Assy. 1
10 505-9-0092-207 505-9-0092-207 Oil Filler Plug 1
11 115-3-1700-104 115-3-1700-104 Release Valve 1
12 * * Oil Seal 1
13 601-7-0006-005 601-7-0006-005 Steel Ball 2
14 511-2-0052-001 511-2-0052-001 Spring 1
15 115-6-1603-104 115-6-1603-104 Screw 1
16 * * O-ring 1
17 * * Back-up Ring 1
18 115-6-1306-108 115-6-1306-108 Pump Piston 1
19 115-4-2100-101 115-4-2100-101 Handle 1
20 518-4-0060-102 518-4-0060-102 Pin 2
21 115-4-1300-104 115-4-1300-104 Handle Sleeve 1
22 677-5-0050-105 677-5-0050-105 “E” Clip 2
23 414-6-1216-107 414-6-1216-107 Needle 1
24 512-2-0067-010 512-2-0067-010 Safety Spring 1
25 * * O-ring 1
26 414-6-1215-307 414-6-1215-307 Safety Valve Screw 1
27 509-9-0145-109 509-9-0145-109 Safety Valve Cap 2
28 649-1-0080-027 649-1-0080-027 Socket Head Bolt 1
29 * * Gasket 1
30 511-2-0048-000 511-2-0048-000 Spring 1
31 115-6-1104-106 115-6-1104-106 Saddle Adapter 1
(*) 115-3-9901-104 115-3-9901-104 Seal Kit -
5
(*) - Indicates items included in, and available only as part of Seal Kit.
N/A - Part is not available as replacement.
Mini Jacks
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
MODELS: J11050 & J11055
Parts List
J11050-M0
rev 08/07
Note: Not all components of the jack are replacement items, but are illustrated as a
convenient reference of location and position in the assembly sequence.
