Parts List
MODELS: P8701 & P8701M
P8701-M0 08/07
Hand Pumps
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
Note: Not all components of the pump are replacement items, but are illustrated as a
convenient reference of location and position in the assembly sequence.
Item Part No.
Description
Qty.
1
H18-6-2112-105 Handle Grip
1
2
H27-4-2102-101 Handle with Grip
1
3
667-5-0120-001
C-clip
2
4
H27-6-1318-101 Piston Pin
1
5
H18-6-1318-100 Pin
1
6
H27-6-2108-105 Pillar
1
7
667-5-0100-005
C-clip
2
8
H28-4-1809-105 Air Vent Screw
1
9
H27-5-1318-105 Pin
1
10
H27-6-2109-107 Pillar Seat
2
11
649-1-0080-003
Socket Head Screw
4
12
H27-4-1750-101 Oil Outlet Base (for
P8701)
1
H27-4-1812-107 4-way Control Valve
w/Base (for P8701M)
1
13
649-1-0080-128
Socket Head Screw
4
14
D05-6-1001-106 Threaded Plug
1
15
649-1-0060-040
Socket Head Bolt
18
16
601-3-0064-106
Washer
18
17
H27-6-6008-101 Reservoir Cover Plate
1
18
*
Packing
1
19
649-1-0080-100
Socket Head Screw
5
20
*
Dust seal
1
21
H27-6-1312-109 Bearing
1
22
H27-6-1309-100 Piston Link
1
23
*
Back-up Ring
1
24
*
O-ring
1
25
H27-5-1306-108 Big Piston
1
26
*
Special Washer
1
27
649-1-0060-020
Socket Head Screw
1
28
H27-6-1601-106 Base
1
29
641-1-0098-103
Socket Head Screw
2
30
H18-4-1901-105 High Pressure Valve
1
31
A17-6-2601-100 Safety Screw
1
32
*
O-ring
1
Item Part No.
Description
Qty.
33
512-2-0082-117
Compression Spring
1
34
H27-6-1605-104 Steel Ball Block
1
35
601-7-0009-001
Steel Ball
1
36
*
O-ring
1
37
*
Back-up Ring
1
38
H27-6-5013-109 Pump Cylinder
1
39
*
O-ring
5
40
*
Back-up ring
1
41
666-5-0180-204
C-clip
1
42
H27-5-1307-100 Small piston
1
43
*
Back-up Ring
4
44
H27-6-1004-108 Steel Tube
2
45
601-7-0008-009
Steel ball
1
46
512-2-0063-104
Compression Spring
1
47
601-7-0012-000
Steel Ball
1
48
552-2-0080-106
Bevel Compression Spring
2
49
*
Special Washer
4
50
H27-6-1606-106 High Pressure Screw
2
51
601-7-0014-013
Steel Ball
1
52
512-2-0061-100
Compression Spring
1
53
601-7-0010-006
Steel Ball
1
54
H27-6-1607-108 Screw
1
55
H27-6-2901-103 Needle Valve, Bypass
1
56
*
O-ring
1
57
*
Back-up Ring
1
58
H27-6-2900-101 Bypass Bushing
1
59
*
Back-up Ring
2
60
*
O-ring
1
61
522-8-0113-107
Filter
3
62
*
Reservoir Gasket
1
63
H27-3-9005-102 Reservoir
1
64
E05-3-9901-103 Drain Plug
1
(*)
H27-3-9900-105 Seal Kit
* indicated items included in, and available only as
part of Seal Kit
