Page 7
7
Parts List
(*) - indicates items included in, and available only as part of Seal Kit
N/A - part is not available as replacement
Item Part Number for Model:
Description
Qty
HU3002
HU3004
HU3006
HU5002
HU5004
HU5006
1
HU3002-01 HU3004-01 HU3006-01 HU5002-01 HU5004-01 HU5006-01 Saddle
1
2
*
*
*
*
*
*
Wiper Seal
1
3
HU3002-04 HU3004-04 HU3006-04 HU5002-04 HU5004-04 HU5006-04 Upper Bearing
1
4
N/A
N/A
N/A
N/A
N/A
N/A
Ram Plunger
1
5
*
*
*
*
*
*
Ram Plunger Seal
1
6
HU3002-08 HU3004-08 HU3006-08 HU5002-08 HU5004-08 HU5006-08 Return Spring Assy.
1
7
N/A
N/A
N/A
N/A
N/A
N/A
Cylinder Housing
1
8
*
*
*
*
*
*
Washer
2
9
HU3002-11 HU3004-11 HU3006-11 HU5002-11 HU5004-11 HU5006-11 Screw
2
10
CH38F
CH38F
CH38F
CH38F
CH38F
CH38F
Female Coupler
1
11
HU3002-13 HU3004-13 HU3006-13 HU5002-13 HU5004-13 HU5006-13 Dust Cover
1
12
N/A
N/A
N/A
N/A
N/A
N/A
Hex Screw
2
13
N/A
N/A
N/A
N/A
N/A
N/A
Handle
1
14
N/A
N/A
N/A
N/A
N/A
N/A
Screw Set
2
(*)
HU3002-99 HU3004-99 HU3006-99 HU5002-99 HU5004-99 HU5006-99 Repair Kit
-
Item Part Number for Model:
Description
Qty
HU5010
HU7504
HU7506
HU10002
HU10006
HU10010
1
HU5010-01 HU7504-01 HU7506-01 HU10002-01 HU10006-01
HU10010-01 Saddle
1
2
*
*
*
*
*
*
Wiper Seal
1
3
HU5010-04 HU7504-04 HU7506-04 HU10002-04 HU10006-04
HU10010-04 Upper Bearing
1
4
N/A
N/A
N/A
N/A
N/A
N/A
Ram Plunger
1
5
*
*
*
*
*
*
Ram Plunger Seal
1
6
HU5010-08 HU7504-08 HU7506-08 HU10002-08 HU10006-08
HU10010-08 Return Spring Assy.
1
7
N/A
N/A
N/A
N/A
N/A
N/A
Cylinder Housing
1
8
*
*
*
*
*
*
Washer
2
9
HU5010-11 HU7504-11 HU7506-11 HU10002-11
HU10006-11
HU10010-11
Screw
2
10
CH38F
CH38F
CH38F
CH38F
CH38F
CH38F
Female Coupler
1
11
HU5010-13 HU7504-13 HU7506-13 HU10002-13 HU10006-13
HU10010-13 Dust Cover
1
12
N/A
N/A
N/A
N/A
N/A
N/A
Hex Screw
2
13
N/A
N/A
N/A
N/A
N/A
N/A
Handle
1
14
N/A
N/A
N/A
N/A
N/A
N/A
Screw Set
2
(*)
HU5010-99 HU7504-99 HU7506-99 HU10002-99 HU10006-99 HU10010-99 Repair Kit
-
(*) - indicates items included in, and available only as part of Seal Kit
N/A - part is not available as replacement
