Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and
position in the assembly sequence.
Double Acting,
Hollow Hole Cylinders
Service Parts
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
MODEL: HDC6003, HDC6006 & HDC6010
Note: To ensure safe and reliable performance, replace worn or damaged parts with BVA Hydraulics Authorized
Replacement Parts only.
(*) - indicates items included in, and available only as part of Seal Kit
N/A - part is not available as replacement
9
Item
Part Number for Model:
Description
Qty
HDC6003
HDC6006
HDC6010
1
H99-6-2305-208
Collar Thread Protector
1
2
H32-6-1105-208
Saddle
1
3
*
O-ring
1
4
*
Back-up Ring
1
5
*
U-cup
1
6
*
Back-up Ring
1
7
*
O-ring
1
8
F32-6-1822-107
Upper-Bearing
1
9
N/A
Cylinder
1
10
N/A
Center Tube
1
11
N/A
Ram
1
12
*
Glyd Ring T Seal
1
13
*
O-ring
1
14
H32-6-1134-104
Bearing (HDC6010 qty: 2)
1
15
*
O-ring
2
16
*
Back-up Ring
1
17
666-5-0800-107
C-clip
1
18
H32-6-1133-102
Bearing
1
19
*
U-cup
1
20
*
Back-up Ring
1
21
H02-4-6001-104
Female Coupler
2
22
H02-4-6003-108
Dust Cap
2
23
H55-3-1806-106
Handle Assembly
2
24
F10-3-1610-104
Safety Valve
1
(*)
F32-3-9902-107
Seal Kit
-
