Note: Not all components of the pump are replacement items, but are illustrated as a convenient reference of location and
position in the assembly sequence.
Double Acting,
Hollow Hole Cylinders
Service Parts
MODELS: HDC10001, HDC10003, HDC10006 & HDC10010
Note: To ensure safe and reliable performance, replace worn or damaged parts with BVA Hydraulics Authorized
Replacement Parts only.
(*) - indicates items included in, and available only as part of Seal Kit
N/A - part is not available as replacement
11
Item
Part Number for Model:
Description
Qty
HDC10001
HDC10003
HDC10006
HDC10010
1
N/A
H32-6-2309-108
Collar Thread Protector
1
2
H32-6-1106-200
Saddle
1
3
*
O-ring
1
4
*
Back-up Ring
1
5
*
U-cup
1
6
*
Back-up Ring
1
7
*
O-ring
1
8
F32-6-1823-109
Upper-Bearing
1
9
N/A
Cylinder
1
10
N/A
Center Tube
1
11
N/A
Ram
1
12
*
Glyd Ring T Seal
1
13
*
O-ring
1
14
F32-6-1136-100
H32-6-1138-102
Bearing (HDC10010 qty: 2)
1
15
*
O-ring
1
16
*
Back-up Ring
2
17
666-5-1050-105
C-clip
1
18
H32-6-1137-100
Bearing
1
19
*
U-cup
1
20
*
Back-up Ring
1
21
H02-4-6001-104
Female Coupler
2
22
H02-4-6003-108
Dust Cap
2
23
N/A
H55-3-1806-106
Handle Assembly
2
24
F10-3-1610-104
Safety Valve
1
(*)
F32-3-9903-109
Seal Kit
-
