B&K Precision MDL Series - Datasheet - Manual (Page 6)

Number of
Slots
Power Input
Operating
Temperature
Storage
Temperature
Humidity
4 110/220 V ±10%, 50/60 Hz
32 to 104 ºF
(0 to 40 °C)
14 to 140 ºF
(-10 to 60 °C)
Indoor use, ≤ 95%
Model Type Dimensions (W x H x D) Weight
MDL001 Mainframe
17.5” x 7.2” x 21.6”
(445 x 183 x 549 mm)
34 lbs (15.4 kg)
MDL002
Mainframe
Extension
17.5” x 7.2” x 21.6”
(445 x 183 x 549 mm)
34 lbs (15.4 kg)
MDL200 Module
3.2” x 7.2” x 22.6”
(82 x 183 x 573 mm)
11 lbs (5 kg)
MDL252 Module
3.2” x 7.2” x 22.6”
(82 x 183 x 573 mm)
11 lbs (5 kg)
MDL305 Module
3.2” x 7.2” x 22.6”
(82 x 183 x 573 mm)
11 lbs (5 kg)
MDL400 Module
3.2” x 7.2” x 22.6”
(82 x 183 x 573 mm)
11 lbs (5 kg)
MDL505 Module
3.2” x 7.2” x 22.6”
(82 x 183 x 573 mm)
11 lbs (5 kg)
MDL600 Module
3.2” x 7.2” x 22.6”
(82 x 183 x 573 mm)
11 lbs (5 kg)
Mainframe Specification
Mechanical Specifications
Standard Accessories
6 w w w.bk prec ision.c om
Modular Programmable DC Electronic Load
MDL Series
v111213
Note: Applies to MDL001 mainframe and MDL002 mainframe extension.
Mainframes Power cord, user manual, mainframe extension cable (MDL002 only)
Modules Certificate of calibration and test report
Optional Accessories
Rack mount kit IT-E153A for mainframes MDL001 and MDL002
