B&K Precision 1620A-1623A - Manual User Manual
Page 5
5
Ammeter accuracy
± 7% fs
± 2% + 2 digits
FUNCTIONS
Serial connection
( independent control mode )
Can be connected in series ( within limits of ground proof voltage )
Parallel operation
( master – slave mode )
Can be operated in “one-control” parallel configuration ( only same model )
COOLING SYSTEM
Natural Convection
POWER CONSUMPTION
VA / W
( for rated load of AC 220V )
Approximate 210
Approximate 220
AC INPUT
Voltage , Frequency
120V AC ± 10%, 60 Hz (120/220/230/240V AC ± 10%, 50/60Hz version available)
Operating ambient temperature
5 to 40°C 10 – 80% R.H.
DIMENSIONS AND WEIGHT
Dimensions ( W x H x D )
205 x 115 x 270 ( mm )
Weight
Approximate 6 Kgs
Approximate 7.4 Kgs
FUSE RECOMMENDED
Input fuse F2
AC 100V, 110V, 120V
3AF
AC 220V, 230V, 240V
2AF
Internal fuse F1
500mAF
NOTE: Specifications and information are subject to change without notice. Please v
or the most current product information.
