The power supply usually displays the actual voltage and current value. Press
twice to check the set value for voltage and current. The display will blink for 3
seconds while displaying the set values.
Shift Shift
Check the Set Voltage and Set Current Value
Cursor Position and Step Size
A
B
C
D
Cursor position Voltage step size Current step size
1V
0.1V
0.01V
1A
0.1A
0.01A
0.001A
Key Lock Function
OVP Function
Press then press and hold the
(Setup) key for 3 seconds.
Afterwards the LCD will display OVP
and you can adjust the OVP value using
the cursor keys and the
knob.
Shift Shift
D V/A D V/A
A A B B
OCP Function
The output of the power supply will
automatically turn off if the OVP and
OCP value are less than the actual
voltage and current value. Default
setting are OVP=61V and OCP=5.1A.
Note
This function locks the keyboard to prevent unintended modification of power
supply settings. Press (Shift LED will be lit), followed by the (Lock)
key. Now the keys and the knob are locked and the Lock LED is lit. Press the
Shift key followed by the Lock key again to disable the Lock function.
C C Shift Shift
V
A
CV CC
OVP OCP
OFF Shift
Lock Preset
A B C D
OVP Value
100W Multi Range 60V/5A DC Power Supply
9110
V
A
CV CC
OVP OCP
OFF Shift
Lock Preset
A B C D
OCP Value
100W Multi Range 60V/5A DC Power Supply
9110
After the OVP value is set, press to
enter OCP mode. Use the cursor keys
and the knob to set the
OCP value.
C C
A A B B
