Room Entry Sensor (RMA-RE1-SEN)
AVTECH Software, Inc. Page 3 of 3 AVTECH.com
1. Scroll down to “Switch Sensor Settings.”
2. Find the switch sensor label that matches the port you connected your Room Entry
Sensor to. For example, if you used the first switch sensor port on your Room Alert,
look for “Sensor 1 Label”; if you used the second, look for “Sensor 2 Label,” and so on.
3. In “Sensor X Label,” you may leave the default name or enter something more
descriptive, such as “Ext Room Entry,” as shown here.
4. In “Alarm On,” choose “Open” if you want alerts sent when the entry point is open (i.e.,
the magnet and proximity switch are apart); choose “Closed” if you want alerts sent
when the entry point is closed (i.e., the magnet and proximity switch are together).
5. If you have any “Alarm Profiles” configured, you may choose one from the drop-down
list. Otherwise, you may leave the default, “No Alarm.”
6. Click Accept Changes at the bottom of your screen to temporarily save your settings.
You may now navigate to another screen; however, if you close the web interface before
the next step, you will lose your changes.
7. Click Save Settings in the navigation bar to the left of your screen. Your Room Alert
will automatically reboot and commit your changes.
With AVTECH’s Device ManageR Software For Advanced Functionality
For advanced functionality and easy management of
multiple units, configure your Room Entry Sensor with
AVTECH’s Device ManageR, the software that comes
FREE with the purchase of any Room Alert monitor.
You may download the current version from your
customer account at
AVTECH.com/Downloads while
your Maintenance, Support & Update Service (MSUS)
is current. If your service and access has lapsed, please
contact your Product Specialist about reactivating them.
Room Entry Sensor Features & Specifications
Environment Condition Monitored .................. Proximity (Open/Closed)
Type Of Sensor ................................................... Switch
Normal State ................................................... Closed (Proximity switch & magnet together)
Power Supply ...................................................... Monitoring unit
Sensor Cable Type ............................................. Low-voltage, two-wire speaker cable
Included .......................................................... Yes
Length ............................................................. 25'
Maximum Extendible Length ......................... 900'
Operating Temperature Range......................... -40º F to 221º F (-40º C to 105º C)
Compatible Room Alert Monitors .................... Any Room Alert or Wireless Sensor Hub model
