User’s Manual
2.2 ADF Paper Chute
1. Lift the paper chute to about 45 degrees.
2. Pull the paper-chute wire leg down to the grips on the
document cover.
3. Slightly press the paper chute to snap the wire leg into
the grips on the document cover.
4. Pull out the paper chute extension to the length you
want.
paper chute
extension
paper
chute
wire leg
Figure 2-3 Install the ADF Unit
2-5
