6
Technical Specifications
Item Description
Communications  Bluetooth V.2.1 + EDR
 USB 2.0
Wireless Frequency 2.4 GHz
Input Voltage Range 12 VDC
Supply Current 200 mA @ 12 VDC
Operating Temperature 0°C to 50°C (ambient)
Storage Temperature -20°C to 70°C (ambient)
Dimensions (L x W x H) 147.5 mm (5.80
”) x 85.5 mm (3.37”) x 29.0 mm (1.14”)
Weight 0.215 kg (0.473 lb)
Capabilities
When used in conjunction with the display table or the OEM softwares from
the PC, the Bluetooth Diagnostic Interface device is able to perform the
following functions:

Auto diagnostics to read and clear the error memory, to display system
parameters and the status of the ECU;

Activation, adjustments and configurations that are essential for ensuring
a complete repair;

Resetting the service lights or the airbag systems;

Configuration of the ECUs, keys and remote controls, etc.
