caution
Product damage
• Do not over-extend or over-retract jacks. The electric jack has an
internal slip clutch to help prevent damage; when clicking sound is
heard, release switch. Continuing to hold the switch will wear out the
slip clutch or cause damage to the motor.
Truck camper
To lifT
extend front
jacks first Extend front jacks so camper is 4˝ higher in
front than in the rear. ( fig 2).
extend all jacks
Once the camper front is higher than the rear,
press and hold the
all jacks button
, extend
( ). Release when the camper is at the
proper height.
individual jack Use the individual jacks buttons to adjust an
adjustment individual jack.
note
: A maximum of two
individual jacks can be operated at any time.
Press and hold the extend or release buttons
for the individual jacks as needed to keep the
front of the camper 4˝ higher than the rear,
to prevent tipping over the camper. Keep all
corners within 4˝ of level with each other.
m
caution
Personal injury & Product damage
• Do not enter camper after it is removed from truck until it is
lowered to its lowest position. This will minimize sway which could
cause structural damage to the camper, jacks or injury to persons.
To lower
retract rear jacks Retract rear jacks so camper is 4˝ lower in
first rear than in the front. (
fig
3).
retract all jacks Once the camper has the rear lower than the
front, press and hold the all jacks button ,
retract ( ). Release when the camper is at
the proper height.
individual jack Use the individual jacks buttons to adjust an
adjustment
individual jack.
note : A maximum of two individual
jacks can be operated at one time. Keep all
corners within 4˝ of level with each other.
REmovIng CampER fRom tRuCk
Disconnect electrical connection between camper and truck (refer to
your camper operation instructions or contact the camper manufacturer
for more information). Follow the instructions from the “
to lift ” or “ to
lower truck camper ” sections and fig 2 and 3. Raise camper until bottom
of camper clears truck bed. Slowly drive truck from underneath camper.
Lower camper to lowest possible position without any part of camper
touching the ground.
Loading camper on Truck
Following the instructions “ to lift ” or “ to lower ” truck camper sections
and
fig
2 and 3, raise camper high enough to clear truck bed. Carefully
back truck under camper making sure not to damage any portion of the
camper or jacks. Camper should be centered in truck bed with front
of camper as far forward in truck bed as possible. Attach electrical
connections between truck and camper, (refer to your camper operating
instructions or contact the camper manufacturer for further information).
Lower camper into truck bed, then fully retract all jacks.
Manual Override Operation: To manually extend or retract jack, unplug jack
from camper to disable the jack motor’s dynamic brake. Place manual
override handle (
fig
1-A) into alignment tube (
fig
1-B) and engage drive
pin. Rotate handle counter-clockwise to raise or clockwise to lower
camper. Plug the jack back into camper to activate the jack motor’s
dynamic brake.
2
Press and hold
Extends single jack.
Press and hold.
Retracts single jack.
Press and hold Extends single jack.
Press and hold. Retracts single jack.
care not to apply power to the motor/accessory connectors, as they
utilize the same connector. Doing so will void the unit’s warranty.
SET uP OF wIRELESS REMOTE
m
warning
Personal injury & Product damage
• Do not replace or charge batteries in a potentially explosive
atmosphere. Contact sparking may occur while installing or removing
batteries and cause an explosion.
• All batteries can cause property damage and/or bodily injury such
as burns if a conductive material such as jewelry, keys or beaded
chains touches exposed terminals. The material may complete an
electrical circuit (short circuit) and become quite hot. Exercise care
in handling any charged battery, particularly when placing it inside a
pocket, purse or other container with metal objects.
REMOTE BATTERY INSTALLATION:
1. Firmly slide battery cover (remote back) down to remove.
note: The audio cable can optionally be used to power the
transmitter directly from the switch assembly.
2. Insert one 9V battery.
3. Replace the battery cover and slide up until secure.
The battery type is 9V alkaline battery which will provide approximately
45 minutes of continuous use.
OPERatIOn
m
warning
camPer can tiP over
• Sandy/soft/spongy ground may cause jacks to sink; camper may tip over.
Jack must be on firm solid ground prior to operation.
• Insure area below and around jack is clear of obstructions.
• Do not place blocks under the jack for additional ground clearance.
• Always keep the front of camper higher than or equal to the rear
of the camper. Never allow either side or end of camper to be more
than 4˝ out of level (
fig
2 and 3).
1. Remove the hand held remote control from its secure compartment.
2. Reinstall battery.
3. Unit is in a low power sleep mode when not in use. To activate the
unit, press the “WAKE” button on the switch assembly. The unit
will awaken and the red ACTIVE LED will illuminate. The unit will
automatically deactivate and enter sleep mode 10 minutes after the
last operation of the system.
4. When finished, the LED on the activation switch must not be lit.
5. Activate the RF transmitter by pressing the POWER+SELECT button.
The transmitter will power up and indicate the green LED.
6. The transmitter can be used to control either JACKS or
ACCESSORIES. When the green LED is active, the transmitter is
controlling JACKS. When the yellow LED is active, the system is
controlling the accessory motors.
7. When controlling jacks, the following operations are possible.
• Extension or retraction of an individual jack.
• Extension or retraction of all 4 jacks.
• Paired operation - adjacent jacks can be operated simultaneously
by holding down two jack buttons.
8. When controlling accessories, only one accessory may be powered at
a time. Multiple accessory button presses are ignored.
OPERATION:
Associate the transmitter with the base receiver:
• Power the system by pressing the WAKE button on the activation
switch (Q). The red ACTIVE LED should blink 2 flashes with a
pause. This indicates that the system is in the default shipment
state, and has no RF transmitter associated with it.
• Power the RF transmitter by pressing the POWER+SELECT button.
The green LED on the transmitter will illuminate. The transmitter will
remain powered for 1 minute.
• Hold down the WAKE button on the activation switch (Q) for 10
seconds. The system will enter LEARN TRANSMITTER mode which
is indicated by the red ACTIVE LED flashing quickly. In this mode,
the base receiver will associate itself with the next transmitter that is
received.
• Press any jack button on the transmitter. The base unit will see the
transmitter and associate itself with it. At this point, the red LED
should be on solid, and the blue LED will indicate detection of
transmitter RF signal.
Press and hold Extends single jack.
Press and hold. Retracts single jack.
Press and hold Extends single jack.
Press and hold. Retracts single jack.
