Astro Pneumatic 7300 Super Stand - Universal Rotating Parts Work Stand User Manual
Mounting solutions, Product information, Super stand - universal rotating parts work stand

Important
When unpacking, check the parts diagram and part number
listing on page 3 to make sure all parts are included. If any
parts are missing or damaged, please call your distributor.
Unpacking
www.astrotools.com
Product Information
Astro Pneumatic Tool Co. warrants our products to the original user against defective
material or workmanship for a period of 1 year from the date of 1st use. Astro
reserves the right to determine whether the product failed because of defective
material, workmanship or other causes and to charge back for missing parts. Astro
Pneumatic Tool Co., at its discretion, will repair products covered under this warranty
free of charge. The original user is to return the product (with the exceptions listed
below) with the distributor’s name, address, adequate proof of date of purchase or a
copy of warranty card, and a short note explaining the problem.
Failures caused by
accident, alteration, or misuse are not covered by this warranty.
Astro Pneumatic Tool Co. or its authorized service representatives must perform all
warranty repairs. Any repair to the product by unauthorized service representatives
voids this warranty. The rights under this warranty are limited to the original user and
may not be transferred to subsequent owners.
This warranty is in lieu of all other warranties, expressed or implied, including
warranties of merchantability and fitness for a particular purpose. Some states do not
allow the exclusion of limitations of incidental or consequential damages so the above
limitations may not apply to you. All claims must be sent to:
Astro Pneumatic Tool Company
P.O. Box 251935
Los Angeles, CA 90025
PLEASE DO NOT RETURN ANY PRODUCT TO THE P.O. BOX.
CALL 1-800-221-9705 FOR INSTRUCTIONS.
The Universal Astro Super Stand can
handle any panel, fender, door, hood, or
bumper to make repairs and refinishing easy
The Astro Super Stand comes with 8
adjustable bars to fit almost any panel
securely
The Astro Super Stands portability allows
for fast and easy moving of the part from the
prep. station to the spray booth
The Astro Super Stand's unique design
allows for single handed rotation of panels
350 degrees in 16 degree increments
Weight capacity: 200lbs
•
•
•
•
•
7300
Super Stand
- Universal Rotating Parts Work Stand
page 1
MOUNTING SOLUTIONS
IF YOU NEED
FURTHER ASSISTANCE PLEASE
CONTACT YOUR NEAREST DISTRIBUTOR, OR
ASTRO PNEUMATIC TOOL COMPANY AT
(800)221-9705.
CHROME
HOOD
DOOR
BUMPER
7300
Super Stand
- Universal Rotating Parts Work Stand
page 4
PART MOUNTING
INSTRUCTIONS FOR
MODEL 7300
Due to the universal nature of this unit and its
capabilities to mount many types of
automobile parts, mounting instructions must
be given in a general manner. When
mounting any part you must first determine
what would be the safest way to secure the
automobile part to the Part Stand.
Begin by examining the specific part that
is being mounted and look for holes on the
partthat will allow the Suspend Arm (part
#1) or Prop Arm (part #2) to be inserted
into.
1)
Hints:
Select holes that are as close to the size of
the hook/straight mount for best support.
Select holes at the furthest point on the part
being mounted for better support.
Suspend Arm and/or Prop Arm can be set
at an angled position for wider range and
support.
Suspend Arms and Prop Arms can be used
separately or in conjunction.
Suspend Arms have hook on one side and
straight mount on opposite side. Depending
on size of hole selected to mount part,
select which will secure part best.
Prop Arms have holes at the end which can
be used to secure part being mounted. If
part being mounted has a lip/tab with hole,
align the hole on the Prop Arm with the hole
on the lip/tab and secure by using a nut &
bolt (not included).
•
•
•
•
•
•
Begin mounting process by deciding length
necessary for Suspend Arm/Prop Arm.
Secure Suspend Arm/Prop Arm into place
by tightening knobs.
Mount part onto Suspend Arm/Prop Arm.
Before proceeding to next step, assure that
part is secure and weight is well distributed
and will not cause stand to tip over.
Next, mount bottom of part to Suspend
Arm/Prop Arm. Follow instructions in step 1.
Assure that part is mounted securely. Test
by slowly rotating part.
2)
3)
4)
5)
