Alpha Technologies XM3-HP Series - Quick Start Guide User Manual
Total power solutions, Cableups, Quick start guide
Total Power Solutions
CableUPS
®
Quick Start Guide
Verify battery voltage, cable color, connection and polarity are correct before proceeding.
WARNING!
1
Battery Connector
2
Battery Breaker
3
Precision Temperature Sensor
(PTS) Connector
4
LRI Connector
5
Smart Display
6
DOCSIS Transponder Battery Sense
Harness Connector
7
RF Connector
8
Tamper Switch Connector
9
Output 1 (Primary) / Output 2 (AlphaDOC)
10
APPs Card
11
Smart AlphaGuard Connector
11
10
1
3
4
8
6
7
9
5
2
